No bezel open frame TFT 17" HD LCD monitor with USB touch DVI VGA
1. Resistive,IR or capacitive touch is available
2. DVI,TV ,AV,Speaker,VGA,etc is optional
3. Plastic Case or Metal case or open frame
4. USB or RS232 for touch screen
5. 4 wire resistive touch or 5 wire resistive touch/CAPC/IR option
LCD Panel Characteristics
Screen Size
17inch LED Panel
Resolution
1280(H)*(RGB)*1024(V)
Aspect Ratio
4:3
Brightness
300cd/m2
View Angle
80x80(H),80x80(V)
Contrast Ratio
1000:1
Touchscreen Characteristics (Optional)
Touchscreen Type
4-Wire Resistive
5-Wire Resistive
Projected Capacitive
Saw Touch
IR Touch
Surface Hardness
3H
4H
7H
7H
7H
Working Life
10 millions times
10 millions times
10 millions times
10 millions times
10 millions times
Transparency
82%(±3%)
88%(±3%)
95%(±3%)
95%(±3%)
95%(±3%)
I/O Interface (Optional)
VGA
1 x VGA
USB
1 x USB
DVI
1 x DVI
Power Supply
Voltage
Single 12 V DC power input
Power Comsumption
< 20W
Operating Environment (for reference, if you have special requirements on the temperature, pls inquiry our sales)
Operating Temperature
-20~60° C (-4~140° F)
Humidity
5~95% @ 40° C, non-condensing
Vibration
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
Enclosure
Material
Aluminum Bezel / Stainless Steel
Color
Black/Silver/White
VESA Mounting
75*75mm 100*100mm
Product Dimensions
Dimensions (L x W x H)
TBD
Net Weight
TBD
Packing Details
Carton Size (L x W x H)
TBD
Gross Weight
TBD
Accessories
1x2.6A Power Adapter with cable
