LCD Panel Parameters
|
|
|
Screen Size
|
7 inch LED Panel
|
|
Resolution
|
1024(H)*(RGB)*600(V)
|
|
16:9Aspect Ratio
|
16:9
|
|
Brightness
|
500cd/m2
|
|
View Angle
|
80x80(H),80x80(V)
|
|
Contrast Ratio
|
500:1
|
|
Voltage
|
12V DC input
|
|
Power Comsumption
|
< 20W
|
|
Operating Temperature
|
-20~60° C (-4~140° F)
|
|
Humidity
|
5~95% @ 40° C, non-condensing
|
|
Vibration
|
5-500 Hz, 0.026 G²/Hz, 2.16 Grms, X, Y, Z, 1 hour per axis
|
|
Material
|
Aluminum Bezel / Stainless Steel
|
|
Color
|
Black/Silver/White
|
|
VESA Mounting
|
75*75mm 100*100mm (optional)
|
|
Touchscreen Characteristics (Optional)
|
|||||
|
Touchscreen Type
|
4-Wire Resistive
|
5-Wire Resistive
|
Projected Capacitive
|
Saw Touch
|
IR Touch
|
|
Surface Hardness
|
3H
|
4H
|
7H
|
7H
|
7H
|
|
Working Life
|
10 millions times
|
10 millions times
|
10 millions times
|
10 millions times
|
10 millions times
|
|
Transparency
|
82%(±3%)
|
88%(±3%)
|
95%(±3%)
|
95%(±3%)
|
95%(±3%)
|
|
IO Interface(Optional)
|
|
|
USB
|
1 x USB
|
